MEDRAD® Intego

Reduced radiation exposure, personalized patient care.

MEDRAD® Intego offers reduced technologist radiation exposure, personalized patient care and drives operational efficiency

003_introduction_image_drawing_intego

What is MEDRAD® Intego?

MEDRAD® Intego is a fully automated PET infusion system that allows accurate dose-on-demand administration of 18F-FDG or 18F-NaF from a multi-dose vial while providing shielding and protection to the operator.

How does MEDRAD® Intego work?

A multi-dose vial of FDG is delivered to the nuclear medicine department. The operator will load the custom tungsten vial shield into the system along with a source administration set (SAS).

After the system is primed and the concentration of radiopharmaceutical is checked, the operator can set the next patient injection protocol (weight-based or fixed dose), and inject the radiopharmaceutical.

With each new patient, the operator must change the patient administration set (PAS). With each new vial, the operator must change the SAS.

integointego

What is MEDRAD® Intego Connect?



MEDRAD® Intego Connect is the wireless connection to your PET imaging practice.

Wirelessly

  • Import Worklist from the worklist server to MEDRAD® Intego
  • Export Infusion Records to PACS*
  • Export Radiation Dose to PACS**

What are the benefits of MEDRAD® Intego Connect?

Schedule Management

  • Save time and steps through wireless PET schedule import
  • Efficiently manage daily schedule changes and add-ons
  • Potential reduction of manual data entry errors

Automated Infusion Records and Radiation Dose Tracking

  • Detailed infusion records of 18F-FDG and 18F‑NaF delivered to the patient are automatically transferred to PACS*
  • Estimated total effective dose and absorbed radiation dose ** by organ automatically transferred to PACS

Support Quality Initiatives

  • Reliable and comprehensive information from point of care to study interpretation
  • Support consistent quality records for the practice of ALARA principles and audits with accurate radiation documentation
  • Facilitate communication with patients and referring physicians

PersonalizePatient Care

  • Automated weight-based dosing from a simple touchscreen enables clinicians to administer an accurate, personalized dose for each patient
  • Variable flow rate (0.5 mL/sec or 1 mL/sec) and saline test infusion.
    The lower flow rate may be especially useful in patients with fragile veins

One system, 3.5 Million Proven Results

More than 3.5 million times around the world, MEDRAD® Intego has been trusted for PET infusions.

Worldwide cumulative infusions with MEDRAD® Intego

intego_3.5_million_infusions
  • The MEDRAD® Intego PET Infusion System has an installed base of over 400 units in more than 45 countries.
  • 3,500,000 cumulative infusions worldwide with MEDRAD® Integoand counting2.
  • One PET infusion is done every 26 seconds with MEDRAD® Intego2.

Vial Planner Tool

This tool is intended to calculate the approximate amount of FDG, or NaF, needed to complete a patient schedule with MEDRAD® Intego PET Infusion System. The tool also allows observation of the potential impact of variations to the schedule plan.

006_image-highlight_Vial Planner Tool

Note:The displayed information is fictitious and does not represent any specific patient or dosing data!

Information



    WeightApproximately 783 lbs (355 kg)
    DimensionsApproximately 20 inches (51 cm) wide, 27 inches (67 cm) deep, 51 inches (130 cm) high
    Maximum radioactivity750 mCi (27.7 GBq) for shielding effectiveness
    700 mCi (25.9 GBq) for dose preparation
    Maximum RP volume30 mL
    Maximum RP activity concentration100 mCi/mL (3,700 MBq/mL)
    Dose range1 - 25 mCi (37 - 925 MBq)
     +/- 2% of the measured dose, exclusive of dose
    calibrator calibration factor
    Flow rate0.5 mL/sec or 1 mL/sec
    System radiation profilePeak rate equal to or less than 1.4 mrem/hr
    (0.014 mSv/hr) at 12 inches (30.5 cm) from the surface of the cart at maximum activity
    Power300 VA
    Voltage100-240 VAC
    Frequency50/60 Hz
    Product Catalog
    MEDRAD® Intego PET Infusion System INT SYS 200
    MEDRAD® Intego Connect includes the software licenses catalog numbers SW - WLIST, SW - IRPACS and SW - RDPACS
    Source Administration Set (SAS) INT CSS
    Patient Administration Set (PAS) INT CPS
    Replacement Printer Label Roll 60937964

    References

    1 Based on Patient Administration Set sales data August 2008 – January 2019.

    2 Based on Worldwide Patient Administration Set sales in 2018 and 250 working days year.

    * Or other destination configured for reading DICOM.

    ** Absorbed Radiation Dose is calculated using NUREG/CR-6345
